How to Make a DIY Sunflower Napkin Holder with HiMill D1S Desktop CNC (Laser Mode)
Napkins are a household essential, but ordinary tissue boxes can be quite dull. Today, I’m sharing a super simple project—using the HiMill D1S Desktop CNC in Laser Cutting Mode to DIY a stunning sunflower-themed napkin holder.
No complex carving required; you can finish it in just a few steps! Detailed parameters and the drawing download link are provided at the end.
🛠️ Project Overview
- Project Name Sunflower Napkin Holder
- Equipment HiMill D1S Desktop CNC + Laser Module
- Highlights Laser-Cut Hollow Design, Floral Aesthetics
- Difficulty ⭐ (Beginner-Friendly)
- Processing Time Approx. 5 Minutes
- Material 3mm Basswood Plywood
📋 1. Preparation
Precision is the soul of this project, making laser cutting the perfect choice.
Bill of Materials (BOM)
- Sheet Material: 3mm Basswood Plywood (choose light-colored wood to minimize visible charring).
- Finishing: Wood varnish or water-based paint (optional).
- Auxiliary: Clamps or tape to ensure the board stays flat.
Equipment Setup
- Remove the CNC spindle motor from the HiMill D1S.
- Install the 10W Laser Module.
- Connect the laser control cables.
⚙️ 2. Design & Settings
Step 2.1 Vector Design
The core elements include the circular sunflower center, petals, and the base/side panels. We recommend using DXF Vector Files for the best precision.
Step 2.2 Laser Parameters (Reference)
- Power: 90%
- Speed: 5 mm/s
- Passes: 1 Pass (increase to 2 if needed)
🚀 3. Laser Processing
Watching the laser "draw" the sunflower outline on the wood is incredibly satisfying.
- Secure the Workpiece: Fix the board to the workbed so it is perfectly flat.
- Positioning: Import the file into LightBurn and set the origin.
- Cutting: Click "Start" and let the HiMill D1S cut each part precisely.
🎨 4. Post-Processing & Assembly
- Cleanup: Wipe away any dust or residue.
- Sanding: Lightly sand the edges to remove any burrs.
- Finishing: Apply clear varnish for better durability (optional).
- Assembly: Insert side panels into the base slots and glue the sunflower decorative panels.
🎉 5. Final Result
With this holder, even your napkins become part of your home decor. Place one on your dining table to instantly boost the aesthetic vibe!
Why HiMill D1S Laser?
- Rapid Prototyping: Cut a full set of parts in minutes.
- Smooth Edges: Minimal sanding required, saving significant time.
- Creative Freedom: Bring any vector shape to life easily.
📥 Download The Files
Ready to make your own? Get the free DXF drawing below.
Download Napkin_Holder.zip
